Description
| Weight, W | kg | 2.56 |
| Ouside diameter, D | mm | 75 |
| Number of splines, F | 6 | |
| Number of mounting holes, N | 4 | |
| Diameter of mounting holes, Dm | mm | 8 |
| Length, L | mm | 575 |
| Thread, M | М16 | |
| Pitch of screw thread, t | mm | 1.5 |
| Distance between mounting holes, b | mm | 35 |
| Thread length, Lc | mm | 20 |
| Shaft diameter, Ds | mm | 27 |
| Shaft diameter, Ds1 | mm | 20 |
| Thread, M1 | М35 | |
| Shaft diameter, Ds2 | mm | 17 |
